The RV12 rotary vane vacuum pump is a robust, oil-lubricated pump designed for demanding industrial applications. With high suction capacity and reliable performance, it is particularly suitable for continuous operation and challenging vacuum requirements.
Thanks to rotary vane technology, where movable vanes in a rotating rotor generate the vacuum, the pump delivers consistent and effective performance. It is commonly used in areas such as the packaging industry, vacuum impregnation, drying processes, and other applications that require a stable and efficient vacuum.
The RV12 stands out for its long service life, low maintenance requirements, and high operational reliability. It offers excellent efficiency and dependable performance, even under demanding operating conditions.
RV12 Technical Data
| Technical Specification | 50 Hz | 60 Hz |
|---|---|---|
| Maximum Volumetric Flow | 12 m3/h | 8.4 m3/h |
| Ultimate Pressure (total) | 1.5 x 10-3 mbar | 2.0 x 10-3 mbar |
| Ultimate Pressure GB I (total) | 3.0 x 10-2 mbar | 3.0 x 10-2 mbar |
| Ultimate Pressure GB II (total) | 6.0 x 10-1 mbar | 6.0 x 10-1 mbar |
| High Throughput Mode at Ultimate Pressure | 3.0 x 10-2 mbar | 3.0 x 10-2 mbar |
| Water Vapor Tolerance | 32 mbar | 32 mbar |
| Water Vapor Capacity – GB I | 60 g/h | 60 g/h |
| Water Vapor Capacity – GB II | 290 g/h | 290 g/h |
| Maximum Continuous Inlet Pressure | ||
| High Vacuum Mode | up to 50 mbar | up to 50 mbar |
| High Throughput Mode | up to 500 mbar | up to 500 mbar |
| Maximum Gas Ballast / Purge Pressure | 0.5 mbar | 0.5 mbar |
| Rated Mechanical Power 1-phase (W) | 450 W | 550 W |
| Rated Speed (RPM) | 1470 min-1 | 1760 min-1 |
| Weight | 29 kg | 29 kg |
| Oil Fill Quantity | 1 l | 1 l |
| Oil Type (ULTRAGRADE™ Performance) | 19 | 19 |
| Inlet Flange | NW25 | NW25 |
| Outlet Flange | NW25 | NW25 |
| Sound Level at 50 Hz | 48 dB(A) | 48 dB(A) |
| Sound Level (with Sound Enclosure) at 50 Hz | 41 dB(A) | 41 dB(A) |
| Operating Temperature Range | 12 to 40°C | 12 to 40°C |
Variant Technical Data
| Product Description | Order Number |
|---|---|
| 115/230 V, 1-phase, 50/60 Hz, set to 230 V, IE2 | A65501903 |
| 100/200 V, 1-phase, 50/60 Hz, set to 200 V, IE2 | A65501904 |
| 200–220/380–415 V, 50 Hz, 200–230/460 V, 60 Hz, 3-phase, IE2 | A65501905 |
| 115/230 V, 1-phase, 50/60 Hz, set to 115 V, IE2 | A65501906 |
| 100/200 V, 1-phase, 50/60 Hz, set to 100 V, IE2 | A65501907 |
Accessories
| Product Description | Order Number | |
|---|---|---|
| Cable Sets for Single-Phase IEC Pumps | UK, three-pin plug | A50505000 |
| Northern European plug | A50506000 | |
| North American plug | A50507000 | |
| No plug | A50508000 | |
| Inlet Accessories | Foreline Trap – FL20K | A13305000 |
| Outlet Accessories | Oil Mist Filter – EMF10 | A46226000 |
| Oil Mist Filter – EMF20 | A46229000 | |
| Oil Return Sets | Clean Application (No Gas Ballast) | A50419000 |
| Adjustable Gas Ballast | A50523000 | |
| Vibration Dampers | A24801404 | |
| Spare Parts Sets | Cleaning and Overhaul Kit | A65201131 |
| Sound Enclosure | Low Voltage, 110–120 V | NRD317000 |
| Sound Enclosure | High Voltage, 200–240 V | NRD318000 |
Oil
| Product Description | Order Number |
|---|---|
| ULTRAGRADE™ Performance 19, 1-Liter Bottle | H11025015 |
| Fomblin® YVAC 06/6, 1 kg (532 ml) | H11301019 |
| ULTRAGRADE™ Performance 19 Oil, 4 Liters | H11025013 |
