The RV3 FX rotary vane vacuum pump is an oil-lubricated, compact, and high-performance pump designed for demanding industrial applications. It delivers stable suction capacity and reliable vacuum performance, making it ideal for continuous operation.
Thanks to its proven rotary vane technology, the RV3 FX generates a consistent and efficient vacuum by compressing air with movable vanes in a rotating rotor. This makes it especially suitable for applications such as packaging, drying, vacuum impregnation, and other industrial processes that require a dependable vacuum supply.
The RV3 FX impresses with its compact design, long service life, and easy maintenance. It provides high efficiency and operational reliability, even under challenging conditions.
RV3 FX Technical Data
| Technical Specification | 50 Hz | 60 Hz |
|---|---|---|
| Maximum Pumping Speed | 2.3 m3/h | 3.3 m3/h |
| Ultimate Pressure (total) | 1.5 x 10-2 mbar | 2.0 x 10-2 mbar |
| Ultimate Pressure GB I (total) | 3.0 x 10-2 mbar | 3.0 x 10-2 mbar |
| Ultimate Pressure GB II (total) | 1.2 x 10-1 mbar | 1.2 x 10-1 mbar |
| High-Throughput Mode at Ultimate Pressure | 3.0 x 10-2 mbar | 3.0 x 10-2 mbar |
| Water Vapor Tolerance | 80 mbar | 80 mbar |
| Water Vapor Capacity – GB I | 60 g/h | 60 g/h |
| Water Vapor Capacity – GB II | 220 g/h | 220 g/h |
| Maximum Continuous Inlet Pressure | ||
| High-Vacuum Mode | up to 50 mbar | up to 50 mbar |
| High-Throughput Mode | up to 500 mbar | up to 500 mbar |
| Maximum Gas Ballast / Purge Pressure | 0.5 mbar | 0.5 mbar |
| Rated Power 1-phase (W) | 450 W | 550 W |
| Rated Power 1-phase (W) | 250 W | 300 W |
| Rated Speed (rpm) | 1470 min-1 | 1760 min-1 |
| Weight | 25 kg | 25 kg |
| Oil Filling | 0.7 l | 0.7 l |
| Oil Type (ULTRAGRADE™ Performance) | 19 | 19 |
| Inlet Flange | NW25 | NW25 |
| Outlet Flange | NW25 | NW25 |
| Noise Level at 50 Hz | 48 dB(A) | 48 dB(A) |
| Noise Level (with Silencer Housing) at 50 Hz | 41 dB(A) | 41 dB(A) |
| Operating Temperature Range | 12 to 40°C | 12 to 40°C |
Variant Technical Data
| Product Description | Order Number |
|---|---|
| 115/230 V, 1-phase, 50/60 Hz, set to 230 V, IE2 | A65209903 |
| 100/200 V, 1-phase, 50/60 Hz, set to 200 V, IE2 | A65209904 |
| 200–220/380–415 V, 50 Hz, 200–230/460 V, 60 Hz, 3-phase, IE2 | A65209905 |
| 115/230 V, 1-phase, 50/60 Hz, set to 115 V, IE2 | A65209906 |
Accessories
| Product Description | Order Number | |
|---|---|---|
| Cable Sets for Single-Phase IEC Pumps | UK, 3-pin plug | A50505000 |
| Northern European Plug | A50506000 | |
| North American Plug | A50507000 | |
| No Plug | A50508000 | |
| Inlet Accessories | Foreline Trap – FL20K | A13305000 |
| Outlet Accessories | Oil Mist Filter – EMF10 | A46226000 |
| Oil Mist Filter – EMF20 | A46229000 | |
| Oil Return Kits | Clean Application (No Gas Ballast) | A50419000 |
| Adjustable Gas Ballast | A50523000 | |
| Vibration Dampers | A24801404 | |
| Spare Part Kits | Cleaning and Overhaul Kit | A65201131 |
| Soundproof Enclosure | Low Voltage, 110–120 V | NRD317000 |
| Soundproof Enclosure | High Voltage, 200–240 V | NRD318000 |
Oil
| Product Description | Order Number |
|---|---|
| ULTRAGRADE™ Performance 19, 1-Liter Bottle | H11025015 |
| Fomblin® YVAC 06/6, 1 kg (532 ml) | H11301019 |
| ULTRAGRADE™ Performance 19 Oil, 4 Liters | H11025013 |
