Elmo Rietschle V-VC303 (20) Rotary Vane Vacuum Pump
The Elmo Rietschle V-VC 303 (20) is an oil-lubricated rotary vane vacuum pump designed for continuous industrial operation. It features a flange-mounted motor, dual rotor bearings, an integrated oil–air heat exchanger, and built-in filtration and check valves to ensure reliable vacuum generation.
Hersteller: Elmo Rietschle
Kategorie: uncategorized
Bestellnummer:
1 in stock
The Elmo Rietschle V-VC 303 (20) is an oil-lubricated rotary vane vacuum pump from the V-VC series, designed for continuous industrial operation. It features a flange-mounted motor with dual-sided rotor bearings and an integrated oil–air heat exchanger for efficient cooling. Standard equipment includes a micro inlet filter, vacuum check valve, gas ballast valve, oil separator, and protective cover. The ultimate pressure is approximately 0.1 mbar (abs.), with a pumping speed of around 300 m³/h at 50 Hz and 360 m³/h at 60 Hz. It delivers low noise levels (~70–74 dB(A)), long operating life, and reduced maintenance costs.
V-VC303 (20) Technical Data
| Technical Specification | 50 Hz |
|---|---|
| Power supply | 3ph- 400/690 V |
| Motor power | 5.5 kW |
| Nominal pumping speed | 300 m3 |
| Average sound level | 70 dB(A) |
| Oil capacity | 8 l |
