Under the name T series, Becker offers compact, dry-running rotary vane pressure/vacuum pumps. Six models in the versions DV and DSK are available to choose from; their pumping speed is between 10 and 35 m³/h.
The units generate suction air and blast air in a single unit and do so without oil in the working chamber. This saves a second machine and simplifies installation on the plant. Typical use is on smaller printing, folding and envelope-inserting machines, where sheets are picked up by suction and separated with blast air.
The table that follows lists all six models with their essential data. On ehrler-beck.com you will also find detailed data, variants and accessories. For vanes, filters and other spare parts for the T series, you can submit a request via this shop.
Models of the T series
| Model | Pumping speed | Ultimate pressure | Rated motor power | Read more |
|---|---|---|---|---|
| T 4.10 DV | 10 m³/h | – | 0.37 kW | Read more |
| T 4.16 DV | 16 m³/h | – | 0.55 kW | Read more |
| T 4.25 DSK | 25 m³/h | – | 1.1 kW | Read more |
| T 4.25 DV | 25 m³/h | – | 0.75 kW | Read more |
| T 4.40 DSK | 35 m³/h | – | 1.85 kW | Read more |
| T 4.40 DV | 35 m³/h | – | 1.25 kW | Read more |
Replacement vanes from Ehrler & Beck for this series
Our own vane sets for Becker, Rietschle and Busch pumps: at a fixed price and ready to order.
Vane set 901352-7 for Becker DT / VT / T 3.40 and 4.40DT 3.40, DT 4.40, VT 3.40, VT 4.40, T 3.40, T 4.40252.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901349-7 for Becker DT / VT / T 3.25 and 4.25DT 3.25, DT 4.25, VT 3.25, VT 4.25, T 3.25, T 4.25203.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901347-7 for Becker DT / VT / T 3.16 and 4.16DT 3.16, DT 4.16, VT 3.16, VT 4.16, T 3.16, T 4.16181.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901388-5 for Becker DT / VT / T 4.6 and 4.8DT 4.6, DT 4.8, VT 4.6, VT 4.8, T 4.6, T 4.884.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901334-7 for Becker DVT / T 2.140 and 3.140DVT 2.140, DVT 3.140, T 2.140, T 3.140463.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901333-4 for Becker KDT / KVT / T 2.100 and 3.100KDT 2.100, KDT 3.100, KVT 2.100, KVT 3.100, T 2.100, T 3.100214.00 € All prices net, plus VAT and shippingView the vane set
Vane set 901327-7 for Becker DT / VT / T 3.10 and 4.10DT 3.10, DT 4.10, VT 3.10, VT 4.10, T 3.10, T 4.10172.00 € All prices net, plus VAT and shippingView the vane set
Vane set 90137301-8 for Becker DTLF / VTLF / T 2.400 and 2.500DTLF 2.400, DTLF 2.500, VTLF 2.400, VTLF 2.500, T 2.400, T 2.5001,232.00 € All prices net, plus VAT and shippingView the vane set
